NIB SKF Explorer 23136 CCK /W33 Double Roll Spherical Roller Bearing
Product is new in box, opened for photos.
Fast US shipping
30-day Warranty
Spherical roller bearings can accommodate heavy loads in both directions. They are self-aligning and accommodate misalignment and shaft deflections, with virtually no increase in friction or temperature. The design includes features to facilitate relubrication. The bearings can be used in a modular system, including housings, sleeves and nuts.
- Accommodate misalignment
- High load carrying capacity
- Relubrication features
- Low friction and long service life
- Increased wear resistance
Dimensions
| Bore diameter | 7.087 in |
| Outside diameter | 11.811 in |
| Width | 3.78 in |
Performance
| Basic dynamic load rating | 283 934 lbf |
| Basic static load rating | 395 664 lbf |
| Reference speed | 1 700 r/min |
| Limiting speed | 2 200 r/min |
| SKF performance class | SKF Explorer |
Properties
| Number of rows | 2 |
| Locating feature, bearing outer ring | Without |
| Bore type | Tapered 1:12 |
| Cage | Sheet metal |
| Radial internal clearance | CN |
| Tolerance class for dimensions | Normal |
| Tolerance class for run-out | P5 |
| Sealing | Without |
| Lubricant | None |
| Relubrication feature | With |
| Candidate for remanufacturing | Yes |
Logistics
| Product net weight | 57.849 lb |
| eClass code | 23-05-09-11 |
| UNSPSC code | 31171510 |
