Highlights & Features
Up to 21.6 W/inch3 Power Density for MEG-1K2A
Up to 26.4 W/inch3 Power Density for MEG-2K1A6
Full Power up to 50°C Ambient
Up to 500 kHrs MTBF
2xMOPP Isolation for Medical Application
Output selectable from 2 V to 60 V
Current sharing
Class B Conducted and Radiated EMI
IEC 60601-1-2 4th edition immunity compliance
Normal and Reversed Option for Global Remote On/Off &
Air Flow Direction without power de-rating
Analog and Digital Voltage Trimming
PMBus Ver 1.3 Supported
Intelligent Fan Speed Control
Optional RS485/RS232/USB Communication Adapters
PC GUI for easy parameter setting and monitoring
Conformal coating on PCBAs to protect against common
dust and pollutants
Safety Certifications
IEC 60601-1 CB report
UL 60601-1+CAN/CSA 60601-1
IEC 62368-1 CB report
UL 62368-1+CAN/CSA 62368-1
SEMI F47
CCC GB 17625.1; GB 4943.1; GB/T 9254.1 (MEG-1K2A4)
CQC GB 17625.1; GB 4943.1; GB/T 9254.1 (MEG-2K1A6)
Dimensions
MEG-1K2A4 88.9 x 254 x 40.5mm 3.5 x 10 x 1.59 inch
MEG-2K1A6 127 x 254 x 40.5mm 5 x 10 x 1.59 inch
Input
Input Voltage 90 VAC ~ 264 VAC
Input Frequency 47 Hz ~ 63 Hz
Input Current <15 A
Inrush Current <40 A
Power Factor >0.95 @ rated load
Efficiency Up to 93% 1)
Patient Leakage Current <100 uA normal, <500 uA SFC
Earth Leakage Current <300 uA normal, <1 mA SFC
Output Module
Output Number Single Output Dual Output
Consuming Slots Single Slot Triple Slot Single Slot
Output Voltage 2 V ~ 60 V 8 V ~ 60 V 3.3 V ~ 30 V
Output Power 300 W Max 1200 W Max 240 W Max
Ripple & Noise <1% Vrated pk-pk or 100 mV, which is
larger
Standby Power 5 V / 1 A (No minimum load required)
Environmental
MTBF 500 KHrs
Operation Temperature -20°C ~ 70°C 2)
Operation Altitude 5000 m or 50 kPa
