| Product Type | Straight | Motion | Linear Motion |
|---|---|---|---|
| Style | Standard | Outer Cylinder Material | 440C Stainless Steel Equivalent |
| Outer Cylinder Surface Finish | None | For Shaft Diameter(mm) | 8 |
| Overall Length L(mm) | 24 | Lubrication Type | No Grease (Rust Preventive Oil) |
| Outer Diameter D(mm) | 15 | Type | Straight |
| Length | Single | Ball Recirculating Type | Single |
| Basic Dynamic Load Rating (Details)(N) | 265 | Basic Static Load Rating(N) | 380 |
| Precision | High Grade | Inner Contact Circle Tolerance (Negative Side)(mm) | -0.009 |
| Eccentricity(µm) | 12 | Linear/Rotary Motion | - |
| _Basic Dynamic Load Rating | - | Ball Material | 440C Stainless Steel Equivalent |
| Retainer Material | Plastic (Duracon M90 Equivalent) | Seals | With Seal |
| Material Certificate | - | Material Certificate: Material | - |
| RoHS | 10 | - |
