| Series Name | Oldham | Allowable Misalignment | Angular / Eccentricity / Axial |
|---|---|---|---|
| Application | Standard | Allowable Torque Range(N⋅m) | 20.01 to 50.00 |
| For Shaft Size d1(mm) | 18 | For Shaft Size d2(mm) | 18 |
| O.D. D(Ø) | 38 | Overall Length(mm) | 39.5 |
| Maximum Rotational Speed Range(r/min) | 2001~4000 | Features | High Torsional Rigidity / High Torque Type / Low Moment of Inertia / Keyway Option |
| Body Material | [Stainless Steel] 304 Stainless Steel Sintered Alloy | Category | Coupling Main Body |
| Allowable Torque(N⋅m) | 50 | Maximum Rotational Speed(r/min) | 4000 |
| Allowable Angular Misalignment(deg) | 1.5 | Allowable Lateral Misalignment Range(mm) | 0.41 to 1.0 |
| Allowable Lateral Misalignment(mm) | 1 | Buffer Part Material | [Aluminum Bronze] Aluminum Bronze (Solid Lubricant Embedded) |
| Allowable Axial Misalignment(mm) | +0.3/-0.3 | Moment of Inertia(kg·m2) | 1×10-4 |
| Mounting Method | Set Screw | Shaft Bore Shape | Hole with Keyway d1/d2 Side |
| Shaft I.D. d1 Change Hole Dia. [LDC] Specified in 0.1mm Increment | - | Shaft I.D. d2 Change Hole Dia. [RDC] Specified in 0.1mm Increment | - |
| RoHS | 10 |
