Enlarging lenses have no built-in helicoid, because they are usually focused using a bellows on the enlarger. Therefore, in order to focus an enlarging lens when it is used on a camera, a helical mount is needed. The Unifoc 12 Helical Mount makes this possible. It is extremely compact with 12mm of displacement.

In the shortest setting, the mechanical length is 17.4mm. It comes complete with a focus locking screw.

Mount type: helical
Displacement: 12 mm
Length: 17.4 mm

Description

The Schneider Optics Apo-Componon 4.0/60 (LEICA Mount Part Number 12-018928, V-Mount Part Number 25-014802) is a 60 mm focal length enlarging lens with 60 mm image circle for large format sensors and short working distance. The Apo-Componon 4.0/60 lens can also be used in reverse position. The modular system with wide-ranging accessories such as helical focus barrel (Unifoc 58 and 76), extension tubes, and adapters for various cameras, can be used for all kind of sophisticated applications from web inspection to laser triangulation.

This, the fast F/# of 4.0 and low chromatic aberration, as well as extremely low distortion make these lens unique. Vibration insensitivity for stable imaging performance even when the lens used in harsh industrial environmental, as common in OLED inspection and quality control systems.

Features

Key Features of the APO-Componon 4.0/60 25-014802

Large Format

Short working distance

Modular: Unifoc 58 and 76 focus helical barrels, extension tubes, various camera adapters

Possibility to be used in retro position

Vibration insensitivity for stable imaging performance

Industry-compatible V-mount interface(25-014802)

Lockable distance and aperture settings

Continuous aperture adjustment, guaranteed long-term stability

100% quality control guarantees reliability and constant quality

Low maintenance requirements, therefore high system reliability
