• 1031635
• DISCONTINUED BY MANUFACTURER
• ADHESIVE APPLICATOR
• E-400 SERIES
• ELECTRIC
• TOP FEED
• 240 V
• 125 W
• (ES401-RC-T-F)

The HART Communication Output Module (FBM215) contains eight channel-isolated outputs. The FBM215 supports any mix of standard 4 to 20 mA devices and HART devices. The FBM215 serves as a HART communications field device host, enabling the Foxboro Evo system to request and receive two digital messages per second from each field device. The message pass-through capability can be used to support HART universal, common practice, and device-specific commands, but not the burst communication mode.

FEATURES

Key features of the FBM215 module are:

-Eight channel-isolated output channels, each providing one of the following outputs:

 • Standard 4 to 20 mA analog output signal

• Digital HART Frequency Shift Keying (FSK) signal superimposed on a 4 to 20 mA analog output signal

FSK modem dedicated to each output channel for bi-directional digital communications with a HART field device

Galvanic isolation of all output channels from each other, and from ground and module logic

Support for HART universal commands necessary to interface the field device with the Foxboro Evo system database

Rugged design suitable for enclosure in Class G3 (harsh) environments

Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM215.

The FBM215 has a rugged extruded aluminum exterior for physical protection of the circuits. Enclosures specially designed for mounting the FBMs provide various levels of environmental protection, up to harsh environments per ISA Standard S71.04.

VISUAL INDICATORS

Light-emitting diodes (LEDs) incorporated into the front of the module provide visual indication of the module’s operational status, and communication activity of the channels.

EASY REMOVAL/REPLACEMENT

The module can be removed/replaced without removing field device termination cabling, power, or communications cabling.

FIELDBUS COMMUNICATION

A Fieldbus Communication Module or a Control Processor interfaces the redundant 2 Mbps module Fieldbus used by the FBMs. The FBM215 module accepts communication from either path (A or B) of the redundant 2 Mbps fieldbus – should one path fail or be switched at the system level; the module continues communication over the active path.

MODULAR BASEPLATE MOUNTING

The module mounts on a modular baseplate, which accommodates up to four or eight FBMs. The modular baseplate is either DIN rail-mounted or rack mounted, and includes signal connectors for redundant fieldbus, redundant independent DC power, and termination cables.

The FBM238 24DI/8DO Module provides twenty-four digital inputs with eight digital output channels. Associated Termination Assemblies (TAs) and Termination Assembly Adapters (TAAs) provide for discrete nominal inputs of 30 V DC, 60 V DC, 120 V AC/125 V DC or 240 V AC and nominal outputs of 60 V DC, 120 V AC/125 V DC or 240 V AC. The module performs signal conversion required to interface the electrical input signals from the field sensors to the Module Fieldbus.

Depending on the type of I/O signal required, the Tas or TAAs support current limiting devices, high voltage attenuation circuits, optical isolation and external power source connections.

FEATURES

- Twenty-four digital input channels, used for either contact sensing, or DC voltage monitoring

- Eight digital output channels, used for either DC output switching with an external source (e.g. to PSS 31H-2S238 control powering of various external loads), or DC output switching with an internal source only (e.g. to power external solid state relays or other similar devices)

- Rugged design suitable for enclosure in Class G3 (harsh) environments

- Supports discrete input signals at voltages of:

• 30 V DC/60 V DC

• 120 V AC/125 V DC

• 240 V AC

- Supports output switching at voltages of:

• 60 V DC

• 120 V AC/125 V DC

• 240 V AC

- Executes the programs for Digital I/O (ECB5), and Ladder Logic (ECB8)

- Various Termination Assemblies (TAs) provide for per-channel isolation and contain:

• High voltage attenuation and optical isolation for inputs

• External power connection for device excitation.

• Output current limiting

Input Channels

Eight isolated and independent thermocouple/mV input channels. One isolated reference junction temperature compensation channel.

Input Range

–10.5 to +69.5 mV dc (–10.5 to +69.5 mV dc equals 0 to 64000 raw counts. Input of 71.419 mV equals 65535 raw counts (full range of module))

Reference Junction

Reference junction temperature compensation is provided by a 4-wire 100 ohm platinum RTD (IEC 751, Class B) at the termination assembly.

Accuracy

MILLIVOLT INPUT : ±0.03% of span (±24 µV) at 25°C

RTD CHANNEL : ±0.03% of span

RTD REFERENCE JUNCTION CONFORMITY : ±0.25°C

THERMOCOUPLE CONFORMITY : ±0.25°C

ACCURACY TEMPERATURE COEFFICIENT : ±50 ppm/°C

RTD REFERENCE JUNCTION MEASUREMENT ACCURACY : ±0.50°C (When using the RTD internal to the Foxboro supplied termination assemblies)

DIFFERENTIAL INPUT IMPEDANCE : 10 MΩ

COMMON MODE VOLTAGE : Up to 30 V ac or 60 V dc

Integration Period

Software configurable

Input Open Circuit Voltage

250 mV dc through 10 M ohms (mV channels)

Input Signal A/D Conversion

Each channel performs A/D signal conversion using an independent Sigma-Delta converter.

Typical Thermocouple Types

B, E, J, K, N, R, S, T and other millivolt signals

Thermocouple Burnout Detection

Full upscale value

Input Channel Isolation

Each channel is galvanically isolated from all other channels and earth (ground). The module withstands, without damage, a potential of 600 V ac applied for one minute between any channel and ground, or between a given channel and any other channel.

CAUTION

This does not imply that these channels are intended for permanent connection to

hazardous voltage circuits. Connection of these channels to voltages greater than

30 V ac or 60 V dc violates electrical safety code requirements and may expose users to

electric shock.

Communication

Communicates with its associated FCM or FCP via the redundant 2Mbps module Fieldbus.

Power Requirements

INPUT VOLTAGE RANGE (REDUNDANT) : 24 V dc, +5%, -10%

CONSUMPTION : 3 W (maximum)

HEAT DISSIPATION : 3 W (maximum)

Calibration Requirements

Calibration of the module and termination assembly is not required.

Industrial Immunity Levels

RoHS COMPLIANCE

Complies with European RoHS Directive

2011/65/EU

The FBM238 24DI/8DO Module provides twenty-four digital inputs with eight digital output channels. Associated Termination Assemblies (TAs) and Termination Assembly Adapters (TAAs) provide for discrete nominal inputs of 30 V DC, 60 V DC, 120 V AC/125 V DC or 240 V AC and nominal outputs of 60 V DC, 120 V AC/125 V DC or 240 V AC. The module performs signal conversion required to interface the electrical input signals from the field sensors to the Module Fieldbus.

Depending on the type of I/O signal required, the Tas or TAAs support current limiting devices, high voltage attenuation circuits, optical isolation and external power source connections.

FEATURES

- Twenty-four digital input channels, used for either contact sensing, or DC voltage monitoring

- Eight digital output channels, used for either DC output switching with an external source (e.g. to PSS 31H-2S238 control powering of various external loads), or DC output switching with an internal source only (e.g. to power external solid state relays or other similar devices)

- Rugged design suitable for enclosure in Class G3 (harsh) environments

- Supports discrete input signals at voltages of:

• 30 V DC/60 V DC

• 120 V AC/125 V DC

• 240 V AC

- Supports output switching at voltages of:

• 60 V DC

• 120 V AC/125 V DC

• 240 V AC

- Executes the programs for Digital I/O (ECB5), and Ladder Logic (ECB8)

- Various Termination Assemblies (TAs) provide for per-channel isolation and contain:

• High voltage attenuation and optical isolation for inputs

• External power connection for device excitation.

• Output current limiting

• CL50GRYPQ
• STACK LIGHT
• 3 COLOR INDICATOR
• 18-30 VDC
• M12 4 PIN CONNECTOR
• INTEGRAL QD
• PNP
• LED
• -40 TO+50 DEGREES C
• IP67
• (10017)

The FDC280 RH101FQ is a distributed, field-mountable controller with an optional fault - tolerant feature, primarily designed for device integration. It can connect to both Ethernet and serial field devices, acquire device data for display and recording, and perform control tasks as well as alarm detection and notification. With its dual-core CPU running different software, it realizes control and device integration functions and can directly communicate with a variety of field devices that support specific protocols.

Processor and Memory: It uses a dual-core ARM® System-on-Chip (SOC), which has high-speed communication capabilities and ECC error detection functions. It can support up to 256 field devices, 8000 I/O points, and a total of 8252 blocks. The memory is 22MB, and the maximum block execution speed is 16,000 blocks per second.

Communication Capability: The Ethernet interface supports speeds of 10/100Mbps or 1Gbps and can be connected via copper cables or optical fibers. There are 4 serial interfaces, each of which can be configured as RS-232, RS-422, or RS-485, and it can support up to 128 RS-485 field devices.

Electrical Characteristics: The input voltage is 24V dc (redundant), and the maximum power consumption of a single module is 8.5W.

Environmental Adaptability: The operating temperature ranges from-20°C to 60°C, the relative humidity is 5% -95% (non-condensing), and it can operate at an altitude of up to 3000m. It can run in a Class G3 harsh environment and is protected by conformal coating.

Physical Specifications The height of a single module is 105mm (116mm including mounting ears), the width is 51.8mm, and the depth is 147mm. The weight is 0.8kg. The fault - tolerant version consists of two processor modules.

In terms of network configuration, the FDC280 supports multiple configuration methods for Ethernet networks. In simplex mode, the non - fault - tolerant FDC280 can be directly connected to Ethernet field devices, which saves wiring. The fault - tolerant FDC280 can connect to Ethernet field devices through a separate network or a common network and supports different IP address settings.

Regarding serial network configuration, the simplex FDC280 is used to connect single - port serial field devices, while the fault - tolerant FDC280 can connect to both dual - port and single - port serial field devices, and can achieve RS - 232 connection through a Y - cable.

It has an excellent reliability design and supports multiple fault - tolerance mechanisms. At the control network level, two FDC280 modules installed on the same baseplate can achieve fault - tolerant communication through the "marriage" operation. The Core 1 CPU has fault - tolerance functionality, and the Core 2 CPU has redundancy functionality. The I/O - side redundancy ensures that on - site I/O signals are not affected during module replacement, effectively improving system availability.

In terms of control and diagnostic functions, the FDC280 is equipped with a variety of control algorithms, which can implement control strategies ranging from simple to complex. It also supports the self - hosting mode and can operate when the host workstation is offline. Meanwhile, it supports using diagnostic drivers to diagnose communication problems without affecting the device interface.

he FBM217 Discrete Input Interface Module is a device used for interfacing discrete input signals in industrial automation applications. Here are the key features and specifications of the FBM217:

Features:

1. Discrete Inputs: Provides 32 discrete input channels.
2. Voltage Range: Supports discrete input signals at voltages of:
   • 15 to 60 V dc
   • 120 V ac/125 V dc
   • 240 V ac
3. Redundancy: Can be used as a single module or in a redundant pair (two FBM217s) to enhance reliability.
4. Rugged Design: Designed for use in harsh Class G3 environments.
5. Program Execution: Executes programs for Discrete Input, Ladder Logic, Pulse Count, and Sequence of Events, with configurable options for Input Filter Time and Fail-Safe Configuration.
6. Termination Assemblies (TAs): Various TAs available, providing high voltage attenuation and optical isolation for inputs, as well as external power connection for device excitation.

Functional Specifications:

• Input: 32 group-isolated channels.
• On-State Voltage: 15 to 30 V dc.
• Off-State Voltage: 0 to 5 V dc.
• Current: 2.2 mA (typical) at 30 V dc Input.
• Filter/Debounce Time: Configurable (No Filtering, 4, 8, 16, or 32 ms).
• Maximum Pulse Count Rate: 250 Hz.
• Isolation (Module/TA Combination):
  • Group isolation for certain TAs (P0916CA, P0916CB, P0916PW, P0916PX, P0916XZ).
  • Channel isolation for others (P0916PS, P0916PT, P0916YA, P0916PY, P0916PZ, P0916YB).
• Communication: Communicates with its associated FCM or FCP via the module Fieldbus.
• Power Requirements:
  • Input Voltage Range (Redundant): 24 V dc ±5%, -10%.
  • Consumption: 3 W (maximum) at 24 V dc.
• Environmental Specifications:
  • Operating Temperature: -20 to +70°C (-4 to +158°F).
  • Relative Humidity: 5 to 95% (non-condensing).
  • Altitude: -300 to +3,000 m (-1,000 to +10,000 ft).

Contains 16 discrete output channels that are compatible with voltages and currents commonly found in industrial plants. The module interfaces electrical output signals from a control processor to the field devices and provides a Fail-Safe Configuration option for the outputs.

Features

• Sixteen discrete outputs
• Supports discrete output signals at voltages of:
• 15 to 60 V DC
• 120 V AC/125 V DC
• 240 V AC
• Each input and output is galvanically isolated
• Rugged design suitable for harsh environments (Class G3)
• Executes Discrete I/O or Ladder Logic program
• Various Termination Assemblies (TAs) with current limiting devices, fuses, and relay outputs
• Visual indicators with LEDs for operational status
• Easy removal/replacement without removing field device termination cabling, power, or communication cabling
• Fieldbus communication with redundant 2 Mbps module Fieldbus
• Modular baseplate mounting for up to four or eight Fieldbus Modules.

Technical Specifications

• Input Voltage Range (Redundant): 24 V DC +5%, -10%
• Consumption (Maximum): 3 W at 24 V DC
• Heat Dissipation: 6.5 W at 24 V DC (with all outputs at 1.5 A each)
• Dimensions: 20 cm x 6.2 cm x 15 cm
• Weight:0.4 kg.

- Triple Modular Redundant (TMR), fault tolerant (3-2-0) operation.

-Hardware Implemented Fault Tolerant (HIFT) architecture.

-Dedicated hardware and software test regimes which provide very fast fault recognition and response times.

- Automatic fault handling without nuisance alarming.

- Time-stamped fault historian.

- Hot replacement (no need to re-load programs).

- Full suite of IEC 61131-3 programming languages.

- Front panel indicators that show module health and status.

- Front panel RS232 serial diagnostics port for system monitoring, configuration and programming.

The FBM232 connects to a single 10 Mbps or 100 Mbps copper Ethernet network to communicate with devices. The FBM232 is connected to Ethernet switches or hubs in order to communicate with one external device or up to 64 external devices. The general network configuration is shown in Figure 1.

Key features of the FBM232 are:

10 Mbps or 100 Mbps Ethernet network transmission rate to/from field device

Communicates with up to 64 field devices I/O software driver is downloadable from a library of available protocols

Up to 2000 DCI block connections

 Integrates field device data into a Foxboro Evo control database using Ethernet connectivity

Field mounted

 Class G3 (harsh) environments.

The FBM244 module contains four 0 to 20 mA galvanically isolated analog input and output channels (eight total). The FBM244 supports any mix of standard 4 to 20 mA devices and HART devices.

Each input channel accepts an analog sensor input such as a 4 to 20 mA transmitter or a self-powered 20 mA source. Each output channel drives an external load and produces a 0 to 20 mA output.

The module performs the signal conversion required to interface the electrical input/output signals from the field sensors and actuators to the redundant Fieldbus.

This module executes the analog I/O application program. The configurable options for this program are Fail-Safe Configuration (Hold/Fallback), Analog Output Fail-Safe Fallback Data, (on a per channel basis), Fieldbus Switching Enable and Fieldbus Switching Time. The module does not provide DPIDA support

-          Four 0 to 20 mA analog input channels, used for a HART analog sensor input such as a PSS 31H-2S244 4 to 20 mA transmitter or a self-powered 20 mA source

-           Four analog output channels, used to drive an external load and produce a 0 to 20 mA output

-          Support for the HART universal commands necessary to interface the field device with the Foxboro Evo system database Both inputs and outputs are galvanically isolated

-           Rugged design suitable for enclosure in Class G3 (harsh) environments

-           Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM244

-           Termination Assemblies for per channel internally and/or externally loop powered transmitters.

FEATURES

Key features of the FBM244 module are:

- Four 0 to 20 mA analog input channels, used for a HART analog sensor input such as a 4 to 20 mA transmitter or a self-powered 20 mA source

- Four analog output channels, used to drive an external load and produce a 0 to 20 mA output

- Support for the HART universal commands necessary to interface the field device with the

Foxboro Evo system database Both inputs and outputs are galvanically isolated

- Compact, rugged design suitable for enclosure in Class G3 (harsh) environments

- Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM244

- Termination Assemblies for per channel internally and/or externally loop powered transmitters.

COMPACT DESIGN

The FBM244 module has a compact design, with a rugged extruded aluminum exterior for physical protection of the circuits. Enclosures specially designed for mounting the FBMs provide various levels of environmental protection, up to harsh environments per ISA Standard S71.04.

EASY REMOVAL/REPLACEMENT

The modules can be removed/replaced without removing field device termination cabling, power or communications cabling.

VISUAL INDICATORS

Light-emitting diodes (LEDs) incorporated into the front of the modules provide visual status indications of Fieldbus Module (FBM) functions.

MODULAR BASEPLATE MOUNTING

The modules mount on a modular baseplate or conversion mounting structure which accommodates up to four or eight FBMs. The modular baseplate is either DIN rail mounted or rack mounted, and includes signal connectors for redundant fieldbus, redundant independent dc power, and termination cables.

FIELDBUS COMMUNICATION

A Fieldbus Communication Module or a Control Processor interfaces the redundant 2Mbps module Fieldbus used by the FBMs. The FBM244 module accepts communication from either path (A or B) of the redundant 2Mbps fieldbus – should one path fail or be switched at the system level, the module continues communication over the active path.

Input Channels Eight resistance temperature detector (RTD) input channels. Each channel is isolated and independent.

Input Range (Each Channel) • FBM203/203D: 0 to 320 ohms. 320 ohms equals 64000 counts. Minimum over range value is 327.675 ohms at a count of 65535.

• FBM203B: 0 to 640 ohms. 640 ohms equals 64000 counts. Minimum over range value is 655.35 ohms at a count of 65535.

• FBM203C: 0 to 30 ohms. 30 ohms equals 64000 counts. Minimum over range value is 30.72 ohms at a count of 65535.

Sensor Current • FBM203/203D: 0.19 mA DC nominal

• FBM203B: 0.19 mA DC nominal

• FBM203C: 0.54 mA DC nominal

Lead Resistance • FBM203/FBM203B: 50 ohms maximum each lead. Any imbalance in extension leads will decrease accuracy.

• FBM203C: 10 ohms maximum each lead. Any imbalance in extension leads will decrease accuracy.

• FBM203D: 50 ohms maximum. Any imbalance in extension leads will not affect accuracy.

PSS 41H-2S203, Rev A 7

FBM203/b/c/d Platinum/Nickel/Copper RTD Input Modules Functional Specifications

Input Channels (8) • Analog Accuracy (Includes Linearity):

◦ FBM203/d: ±0.03% of span

◦ FBM203b: ±0.03% of span

◦ FBM203c: ±0.1% of span

• Accuracy Temperature Coefficient: ±50 ppm/ºC

• Input Signal A/D Conversion: Each channel performs its own A/D signal conversion, using an independent sigmadelta conversion technique.

• Integration Period: Software configurable

• Common Mode Rejection: >125 db at 50 or 60 Hz

• Normal Mode Rejection: >95 db at 50 or 60 Hz

Typical Resistance

Temperature Sensors

Platinum (DIN), Platinum (SAMA), Platinum (IEC), or Nickel (SAMA)

• FBM203/203D:

◦ Platinum: 100 ohms nominal at 0°C

◦ Nickel: 235 ohms nominal at 0°C

• FBM203B:

◦ Platinum: 200 ohms nominal at 0°C

◦ Nickel: 470 ohms nominal at 0°C

• FBM203C: ◦ Copper:

10 ohms nominal at 25°C

Processor Type:

•             Control Processor: ARM® System on a Chip (SOC)

•             Memory:

•             128 MB SDRAM

•             128 MB Flash Memory

•             Error Detection: ECC for single-bit error correction and multiple-bit error detection

Process I/O Communications:

•             Fieldbus Type: HDLC

•             Transmission Rate:

•             2 Mbps for 200 Series FBMs

•             268 Kbps for 100 Series FBMs

Process I/O Capacity:

•             200 Series FBMs:

•             Up to 32 per Expanded Fieldbus

•             Up to 128 FBMs over all four Expanded Fieldbuses with 200 Series FBMs

•             Mixed with 100 Series FBMs: Up to 128 FBMs, e.g., 64 100 Series and 64 200 Series FBMs

•             100 Series FBMs:

•             64 FBMs per PIO bus/baseplate port

•             Total of 128 FBMs per FCP280

•             Competitive Migration Modules: Refer to device-specific Product Specification Sheets

Memory Allocation for Blocks:

•             Classic OLUG: 15.75 MB

•             Enhanced OLUG: 19.75 MB

Maximum Number of Blocks Configured:

•             Total: 8,000 (7,993 user-configured)

Block Executions Per Second:

•             Maximum: 16,000 blocks/second

Maximum Number of Blocks Processed:

•             Depends on: Scan periods and block type selection

Minimum Block Processing Cycle (BPC):

•             Time: 50 ms

Sequence Block Size:

•             Maximum: 32 kB per block

Maximum Number of IPC Connections:

•             Total: 231

•             200 Source Points

•             30 Sink Points

•             1 Internal Use Only

Maximum Number of OM Sink Lists:

•             Total: 75

Maximum OM Scanner Database:

•             BPC ≥ 200 ms: 18,000 points

•             BPC ≤ 100 ms: 7,500 points

Maximum Number of OM Sink Points:

•             Total: 11,250

Configurable Block Periods:

•             Seconds: 0.05, 0.1, 0.2, 0.5, 0.6, 1, 2, 5, 6, 10, 30

•             Minutes: 1, 10, 60

Block Processing Cycle:

•             Options: 0.05, 0.1, 0.2, 0.5, 1.0 seconds

Time to Marry Fault-Tolerant Modules:

•             Less Than: 0.5 seconds

Internal Diagnostics:

•             Self-Checking: At power-up

•             Run-Time Checks: Includes watchdog timer and constant synchronization in fault-tolerant mode

Power Requirements:

•             Input Voltage: 24 V DC (Redundant)

•             Consumption:

•             Single Module: 11 W maximum

•             Fault-Tolerant Pair: 20 W maximum

Regulatory Compliance and EMC:

•             EMC Directive 2014/30/EU: EN 61326-1 Class A

Environmental Specifications:

•             Operating Temperature: -20 to 60°C (-4 to 140°F)

•             Storage Temperature: -40 to +70°C (-40 to +158°F)

•             Relative Humidity: 5 to 95% (Non-condensing)

•             Altitude:

•             Operating: -300 to +3,000 m (-1,000 to +10,000 ft)

•             Storage: -300 to +12,000 m (-1,000 to +40,000 ft)

•             Contamination Class: G3 (Harsh)

•             Vibration: 0.5 g (5 to 500 Hz)

Physical Specifications:

•             Configuration:

•             Single processor module

•             Fault-tolerant version: Two processor modules with integral fault-tolerant connector

•             Mounting: Device-specific 2-position baseplates (horizontal or vertical)

•             Dimensions:

•             Height: 105 mm (4.13 in) or 116 mm (4.7 in)

•             Width: 51.8 mm (2.04 in)

•             Depth: 147 mm (5.79 in)

•             Weight (Maximum): 0.8 kg (1.76 lb)

FEATURES

Key features of the FBM244 module are:

- Four 0 to 20 mA analog input channels, used for a HART analog sensor input such as a 4 to 20 mA transmitter or a self-powered 20 mA source

- Four analog output channels, used to drive an external load and produce a 0 to 20 mA output

- Support for the HART universal commands necessary to interface the field device with the

Foxboro Evo system database Both inputs and outputs are galvanically isolated

- Compact, rugged design suitable for enclosure in Class G3 (harsh) environments

- Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM244

- Termination Assemblies for per channel internally and/or externally loop powered transmitters.

COMPACT DESIGN

The FBM244 module has a compact design, with a rugged extruded aluminum exterior for physical protection of the circuits. Enclosures specially designed for mounting the FBMs provide various levels of environmental protection, up to harsh environments per ISA Standard S71.04.

EASY REMOVAL/REPLACEMENT

The modules can be removed/replaced without removing field device termination cabling, power or communications cabling.

VISUAL INDICATORS

Light-emitting diodes (LEDs) incorporated into the front of the modules provide visual status indications of Fieldbus Module (FBM) functions.

MODULAR BASEPLATE MOUNTING

The modules mount on a modular baseplate or conversion mounting structure which accommodates up to four or eight FBMs. The modular baseplate is either DIN rail mounted or rack mounted, and includes signal connectors for redundant fieldbus, redundant independent dc power, and termination cables.

FIELDBUS COMMUNICATION

A Fieldbus Communication Module or a Control Processor interfaces the redundant 2Mbps module Fieldbus used by the FBMs. The FBM244 module accepts communication from either path (A or B) of the redundant 2Mbps fieldbus – should one path fail or be switched at the system level, the module continues communication over the active path.

The HART Communication Output Module (FBM215) contains eight channel-isolated outputs. The FBM215 supports any mix of standard 4 to 20 mA devices and HART devices. The FBM215 serves as a HART communications field device host, enabling the Foxboro Evo system to request and receive two digital messages per second from each field device. The message pass-through capability can be used to support HART universal, common practice, and device-specific commands, but not the burst communication mode.

FEATURES

Key features of the FBM215 module are:

-Eight channel-isolated output channels, each providing one of the following outputs:

 • Standard 4 to 20 mA analog output signal

• Digital HART Frequency Shift Keying (FSK) signal superimposed on a 4 to 20 mA analog output signal

FSK modem dedicated to each output channel for bi-directional digital communications with a HART field device

Galvanic isolation of all output channels from each other, and from ground and module logic

Support for HART universal commands necessary to interface the field device with the Foxboro Evo system database

Rugged design suitable for enclosure in Class G3 (harsh) environments

Termination Assemblies (TAs) for locally or remotely connecting field wiring to the FBM215.

The FBM215 has a rugged extruded aluminum exterior for physical protection of the circuits. Enclosures specially designed for mounting the FBMs provide various levels of environmental protection, up to harsh environments per ISA Standard S71.04.

VISUAL INDICATORS

Light-emitting diodes (LEDs) incorporated into the front of the module provide visual indication of the module’s operational status, and communication activity of the channels.

EASY REMOVAL/REPLACEMENT

The module can be removed/replaced without removing field device termination cabling, power, or communications cabling.

FIELDBUS COMMUNICATION

A Fieldbus Communication Module or a Control Processor interfaces the redundant 2 Mbps module Fieldbus used by the FBMs. The FBM215 module accepts communication from either path (A or B) of the redundant 2 Mbps fieldbus – should one path fail or be switched at the system level; the module continues communication over the active path.

MODULAR BASEPLATE MOUNTING

The module mounts on a modular baseplate, which accommodates up to four or eight FBMs. The modular baseplate is either DIN rail-mounted or rack mounted, and includes signal connectors for redundant fieldbus, redundant independent DC power, and termination cables.
